Fluoropolymer And PTFE Lined Equal Cross

The Fluoropolymer and PTFE Lined Equal Cross is an essential component for various industrial applications. The product is made of high-quality casting material and is coated with a black powder to provide a durable and long-lasting finish. The round-shaped design of the equal cross ensures easy installation and compatibility with various pipe fittings. The products interior lining is made of high-quality Fluoropolymer and PTFE materials, making it resistant to corrosion, chemicals, and high temperatures. These features make it ideal for use in chemical processing, pharmaceutical, and food industries. The Fluoropolymer and PTFE Lined Equal Cross comes with an 18-month warranty, ensuring that customers receive a quality product.

Specification

• ASME/ANSI B16.5 Class 150
• NB 1/2" to NB 16"
• Carbon Steel Body
• Standard Version: All Flanges Fixed

Material

• Flanges: IS 2062 Plates/ASTM A 105
• Cross: ASTM A 106 Gr. B
• Cast Cross: SG Iron
• Liner: ASTM D 3307
• ASTM D 4894-19

Flange Connection:

• 1 fixed and 3 loose flange
• 4 loose flanges
• Stainless Steel Body
• ANSI B16.5 Class 300 Flanges
