Fluoropolymer And PTFE Lined Header

Introducing our Fluoropolymer and PTFE Lined Header, designed with high-quality materials to provide excellent resistance to chemicals, high temperatures, and pressure. The header is made up of a combination of fluoropolymer/PTFE lining and casting with a polished surface treatment, resulting in a sleek black finish. The round shape of the header ensures easy installation and compatibility with various systems. This product can withstand harsh environments, making it ideal for use in chemical processing, power generation, and oil and gas industries. With a warranty of 18 months, you can be assured of its durability and reliability.

• ASME/ANSI B16.5 Class 150
• NB 1/2" to NB 16"
• Carbon Steel Body
• Standard Version: All Flanges Fixed

Material

• Pipe: ASTM A 106 Gr. B
• Flanges: IS 2062 Plates/ASTM A 105

Liner:

• ASTM D 1457
• ASTM D 3307
• ASTM D 4894-19

Available on request

• Options in Combined Fittings
• Stainless Steel Body
• Special Fabricated Designs
